Atlas C9372 Brake Lathe With Variable Speed Spindle & Feed
Product Code ATBL-9372C

Greg Smith Equipment Sales is pleased to introduce the Atlas C9372 Deluxe combination disc/drum brake lathe as a part of our ever expanding product line.

*Only available in RED

$4,295.00

Add to Cart

Description
Specifications
Downloads
Shipping Info
Articles

Variable speed feed rate

Variable RPM Spindle

Combination disc/drum capability.

Includes quick change adapter set

Precision electric DC servo motors

Only available in RED

Greg Smith Equipment Sales is pleased to introduce the Atlas C9372 combination disc/drum brake lathe as a part of our ever expanding product line. The Atlas C9372 comes complete with a FREE Quick Chuck Tool Package and FREE Brake Lathe Work Bench. This lathe has features comparable to the Accu-Turn® 8989 truck brake lathes.

The Accu-Turn® lathes do NOT include the same adapters and miscellaneous tools that are included (FOR FREE) with the Atlas C9372 brake lathe.

Variable Speed Feed Rates:
The Atlas C9372 Brake Lathe allows you to adjust the feed rate easily with the turn of a dial. This gives you the versatility to reduce the cut time, or increase the micro-finish suitable to your needs.

Eleven Spindle (Arbor) Speeds:
The Atlas C9372 Brake Lathe allows you to quickly and easily change spindle/arbor speeds. Choose from: 70, 95, 120, 145, 170, 195, 220, 245, 270, 295, and 320 RPM. Select higher RPMs for smaller import cars, or lower RPMs for large trucks.

The Atlas C9372 combination disc/drum brake lathe is the best value for a heavy duty commercial brake lathe. The Atlas C9372 brake lathe offers the same features as those brake lathes costing thousands more dollars. The Atlas name is synonymous with high quality automotive shop equipment sold at unbelievably low pricing.

Greg Smith Equipment Sales stocks more automotive after market equipment than any other warehouse in the USA. We offer the most competitive prices on the best products. If you are opening a new automotive service center or just updating or adding equipment to your established service center; you will get your best deal on all your equipment needs from Greg Smith Equipment.

Please call us to find out more about the Atlas C9372 Brake Lathe from Greg Smith Equipment Sales.

Concerned with after sale service? Click here.

Atlas C9372 Brake Lathe Specifications
Rotor Diameter Capacity	4"-24" (102mm-610mm)
Face Width (Max)	5" (127mm)
Thickness (Max)	2.85" (73mm)
Drum Capacity	6"-28" (152mm-711mm)
Depth of Cut	9" (229mm)
Spindle Speed	Variable: 70-320 RPM
Disc Feed Per Spindle	Variable: 0"-0.026" (0mm-0.66mm)
Drum Feed Per Spindle	Variable: 0"-0.026" (0mm-0.66mm)
Maximum Feed Rate Per Minute	2.54" (64.5mm)
Feed Motor	40w (Continuous Duty)
Spindle Motor	600w (Continous Duty)
Shipping Weight	600 LBS.
